Transition Bikes TransAM

The Passionate Pioneer
It will steel your heart.

The classic TransAM returns! After a seven-year hiatus, the reliable trail-shredding hardtail is back in the lineup for a limited time. Now with modern geometry, dual 29-inch wheels, a capable build spec or frameset options, and two classic color schemes, this will be one to hang on to and pass down for many generations. The updated geo encourages hard-charging but rewards thoughtful line choice. It orchestrates a fast-paced ballet through the landscape of your choosing. The new TransAM is ready for the core rider looking to get back to their roots.

AVAILABLE COLORS:

CHROME		CASCADE BLUE

SELECT BUILD

$2,599 USD

$2,699 USD

$799 USD

$899 USD

SELECT SIZE/COLOR

Small

Ships Now

Medium

Ships Now

Large

Ships Now

X-Large

Ships Now

$2,599 USD

IN STOCK: This item will ship within 2 business days

Add To Cart


FRAME	TransAM Chromoly Steel	TransAM Chromoly Steel
WHEEL SIZE	29"	29"
FORK	Marzocchi Z2 (150mm)
HEADSET	FSA No.10/7B/44
STEM	RaceFace Aeffect R (40mm)
HANDLEBAR	RaceFace Chester 35 SM/MD(780x20) LG/XL(780x35)
GRIPS	ODI Elite Flow Lock-On
SADDLE	SDG Bel Air 3
SEATPOST	OneUp Dropper Post SM(150mm) MD(180mm) LG/XL(210mm)
BRAKES	SRAM DB8
ROTORS	SRAM Centerline (200/180mm)
SHIFTER	SRAM NX Eagle MMX
DERAILLEUR	SRAM NX Eagle
CASSETTE	SRAM PG 1230 (11-50t)
CHAIN	SRAM NX Eagle
CRANK	SRAM Descendent 6k DUB (170mm x 30t)
RIMS	WTB ST i30
SPOKES	Pillar Double Butted
HUBS	Novatech D791SB/D902SB
TIRE/FRONT	Maxxis Assegai 3C EXO+ (2.5)
TIRE/REAR	Maxxis Minion DHRII 3C EXO+ (2.4)
INCLUDED	Tubeless Valves & Sealant
WEIGHT	33.0 lbs / 14.97 kg (Size MD)	6.7 lbs / 3.04 kg (Size MD)
	Specs are subject to change at any time. All complete bikes are 95% assembled and packaged for quick and easy final assembly, and as such, Transition Bikes is not able to make special request build spec changes or modifications to packaging.

SIMPLE IS FUN
For the rider who loves refined simplicity with the feeling of the wind in their face as they rip beautiful ribbons of terra firma in both directions, we give you the TransAM. The TransAM brings a feeling of nostalgia and reminds its rider of that first taste of freedom when they were young.

For those that watch The Wizard of Oz while listening to the dark side of the moon. For the Off-Road Cyclist. For the person who doesn't always have a plan but knows that whatever lies ahead will be a most excellent adventure. The TransAM pays homage to the free spirits of yesteryear who found rolling through the mountains on two wheels to be the best way to experience life.

LESS IS MORE
Tech keeps getting more complicated, the list of features gets longer, and the number of batteries keeps increasing. While we too are a bunch of bike nerds, excited about the latest and greatest, at our core we are mountain bikers who simply care about good dirt and good company. The new TransAM has no batteries, no motor, no apps, just a Chromoly frame that'll last a lifetime. In contrast to the times, we wanted to resurrect a bike that was clean and simple. With just enough updates and features like adjustable sliding dropouts, a UDH, and options for different wheel sizes, you can customize your bike to fit your style. Get the complete or the frame, either way, get out there and leave the fuss behind.

ADJUSTABLE DROPOUTS
Run gears or singlespeed, your choice.
MULTIPLE WHEEL OPTIONS
Run 29" or 27.5".
STEEL IS REAL
Nothing beats the feel of our custom butted chromoly steel frame.
STORAGE AND WATERBOTTLE MOUNTS
4 mounting holes on the downtube.

EXTERNAL CABLE ROUTING
Simple and quick setup and on the fly maintenance.
UDH HANGER
The TransAM features the SRAM Universal Derailleur hanger available everywhere.
LIFETIME FRAME WARRANTY
We believe your frame should last longer than you.

EXTERNAL CABLE ROUTING
Simple and quick setup and on the fly maintenance.
UDH HANGER
The TransAM features the SRAM Universal Derailleur hanger available everywhere.
LIFETIME FRAME WARRANTY
We believe your frame should last longer than you.

TransAM Geometry
	SM	MD	LG	XL

A.REACH	430	460	485	510

B.STACK	641	641	646	655

C.EFFECTIVE TT LENGTH	584	614	640	667

D.SEAT TUBE LENGTH	370	400	430	460

E.EFFECTIVE ST ANGLE	76.5°	76.5°	76.5°	76.5°

F.HEAD TUBE LENGTH	105	105	110	120

G.HEAD TUBE ANGLE	64.0°	64.0°	64.0°	64.0°

H.CHAINSTAY LENGTH	425-437	425-437	425-437	425-437

I.WHEELBASE (Based on 425mm Chainstay Setting)	1187	1219	1246	1276

J.BOTTOM BRACKET DROP	50	50	50	50

K.ESTIMATED BB HEIGHT	320	320	320	320

L.STAND OVER HEIGHT	662	667	670	677

M.FORK OFFSET	44	44	44	44

N.SEAT POST INSERTION	250	280	320	350

Frame Specifications

FRONT TRAVEL:	150mm

WHEEL SIZE:	29" F&R

SIZES:	SM, MD, LG, XL

COLORS:	Chrome, Cascade Blue

FRAME MATERIAL:	Chromoly Steel, 4130

FORK AXLE TO CROWN:	574mm (Includes Headset)

FORK OFFSET:	44mm

HEADSET (TOP):	ZS44

HEADSET (BOTTOM):	EC44

BB SHELL:	73mm BSA Thread

CHAINLINE:	52-55mm

REAR BRAKE MOUNT:	160mm IS, Max Rotor Size 223mm

DERAILLEUR HANGER:	SRAM UDH (T-Type Direct Mount)

REAR AXLE:	Transition Axle For UDH, 12mm x 148mm Spacing

ISCG TABS:	ISCG05

SEATPOST DIAMETER:	30.9mm

SEAT CLAMP:	34.9mm

MAX SEATPOST INSERTION:	Small 250mm \| Medium 280mm \| Large 320mm \| X-Large 350mm

MAX CHAINRING SIZE:	34T Single Ring

MAX TIRE SIZE:	29 x 2.5
